750 V
| Part number | VCES (V) | ID (A) | RDS(on) (mΩ) typ. 25 °C | RDS(on) (mΩ) typ. 175 °C | Housing |
|---|---|---|---|---|---|
| Tvj (operational) up to 175 °C | |||||
| 5SFG 0660B07xxxx | 750 | 2 x 485 | 2.4 | 4.2 | B |
| 5SFG 0880B07xxxx | 750 | 2 x 770 | 1.4 | 1.9 | B |
| 5SFG 1100B07xxxx | 750 | 2 x 970 | 1.1 | 1.5 | B |
| Part number | VCES (V) | ID (A) | RDS(on) (mΩ) typ. 25 °C | RDS(on) (mΩ) typ. 175 °C | Housing |
|---|---|---|---|---|---|
| Tvj (operational) up to 175 °C | |||||
| 5SFG 0660B07xxxx | 750 | 2 x 485 | 2.4 | 4.2 | B |
| 5SFG 0880B07xxxx | 750 | 2 x 770 | 1.4 | 1.9 | B |
| 5SFG 1100B07xxxx | 750 | 2 x 970 | 1.1 | 1.5 | B |
